Marathon X068 PSC Double Shafted Direct Drive Blower Motor, 5-5/8" Dia., 3/4 HP, 1075 RPM

Need a PSC (permanent split capacitor) blower motor? Request a quote for the Marathon X068 PSC Double Shafted Direct Drive Blower Motor, 5-5/8" Dia., 3/4 HP, 1075 RPM. We supply Marathon motors and HVAC spare parts across Oman.

A blower motor drives the fan or blower wheel that moves air through the equipment, so a replacement must match the old motor in size, speed, voltage and rotation. Motor type: PSC (permanent split capacitor). Power: 3/4 HP. Speed: 1075 RPM, 3 speeds. Voltage: 208/230 V, 60 Hz, single phase. Current: 5 A. Frame: 48Y. Motor diameter: 5-5/8" (142.88 mm). Shaft: 1/2" (12.7 mm) diameter, 6.81" x 6.81" (172.97 x 172.97 mm) long. Mounting: band. Direct drive. Double shafted. Part code: X068. Manufacturer model number: 048A11O2015.

Before you order: four quick checks

• Match the dimensions: motor diameter 5-5/8" (142.88 mm), shaft 1/2" (12.7 mm) diameter and 6.81" x 6.81" (172.97 x 172.97 mm) long, frame 48Y, mounting band. Compare them with your old motor before you order.
• Check the electrical data: 3/4 HP, 1075 RPM, 208/230 V, 60 Hz, single phase, 5 A. They must match the nameplate of your old motor.
• Check the rotation and the mounting position: a double shafted motor, mounting orientation horizontal, 3 speeds. Capacitor: 10 MFD, 370 VAC required.
• Isolate and lock out the power before working on a motor, and discharge its capacitor before you touch the terminals. Send a photo of the nameplate of the old motor on WhatsApp and we confirm the match.

We supply Marathon motors and fan and blower motors to Muscat, Seeb, Bawshar and every governorate of Oman. Add this motor to your quote or message us on WhatsApp, and we will reply with the price and delivery time.
