Marathon X223 PSC Blower Motor, 5-5/8" Dia., 1/5 HP, 1075 RPM, Carrier OEM Replacement

The Marathon X223 PSC Blower Motor, 5-5/8" Dia., 1/5 HP, 1075 RPM, Carrier OEM Replacement is part of our range of Marathon blower motors, delivered throughout Oman.

A blower motor drives the fan or blower wheel that moves air through the equipment, so a replacement must match the old motor in size, speed, voltage and rotation. Motor type: PSC (permanent split capacitor). Power: 1/5 HP. Speed: 1075 RPM. Voltage: 230 V, 60 Hz, single phase. Current: 1.05 A. Frame: 48Z. Motor diameter: 5-5/8" (142.88 mm). Shaft: 1/2" (12.7 mm) diameter, 2.88" (73.15 mm) long. Mounting: bracket. Part code: X223. Manufacturer model number: 048A11O2050. Listed as an OEM replacement for Carrier.

Before you order: four quick checks

• Match the dimensions: motor diameter 5-5/8" (142.88 mm), shaft 1/2" (12.7 mm) diameter and 2.88" (73.15 mm) long, frame 48Z, mounting bracket. Compare them with your old motor before you order.
• Check the electrical data: 1/5 HP, 1075 RPM, 230 V, 60 Hz, single phase, 1.05 A. They must match the nameplate of your old motor.
• Check the rotation and the mounting position: rotation CW (clockwise) viewed from the shaft end, mounting orientation horizontal, 1 speed. Capacitor: 4 MFD, 370 VAC required.
• Isolate and lock out the power before working on a motor, and discharge its capacitor before you touch the terminals. Send a photo of the nameplate of the old motor on WhatsApp and we confirm the match.

Order from anywhere in Oman, including Seeb, Bawshar and Manah. Add this motor to your quotation list and send the nameplate of your old one; we confirm availability, price and delivery. See more Marathon motors or browse all fan and blower motors.
