Marathon X411 PSC Blower Motor, 5-5/8" Dia., 1/6 HP, 1075 RPM, Lennox OEM Replacement
Marathon X411 PSC (permanent split capacitor) blower motor, 5-5/8" diameter, 1/6 HP, 1075 RPM, 208/230 V, single phase.
- Motor type
- PSC (permanent split capacitor)
- Power
- 1/6 HP
- Speed
- 1075 RPM
- Voltage
- 208/230 V
- Delivery to every governorate. Timing is confirmed with your quotation.
- Not sure it fits? Send the unit nameplate or the old part number and we will match it for you.
- Prefer to talk? Call +968 9762 8602
Description
Looking for a PSC (permanent split capacitor) blower motor? The Marathon X411 PSC Blower Motor, 5-5/8" Dia., 1/6 HP, 1075 RPM, Lennox OEM Replacement is available through our online quotation service anywhere in Oman.
A blower motor drives the fan or blower wheel that moves air through the equipment, so a replacement must match the old motor in size, speed, voltage and rotation. Motor type: PSC (permanent split capacitor). Power: 1/6 HP. Speed: 1075 RPM. Voltage: 208/230 V, 60 Hz, single phase. Current: 1.25-1.1 A. Frame: 48Z. Motor diameter: 5-5/8" (142.88 mm). Shaft: 1/2" (12.7 mm) diameter, 6.06" (153.92 mm) long. Mounting: stud. Part code: X411. Manufacturer model number: 048A11T2008. Listed as an OEM replacement for Lennox.
Before you order: four quick checks
- Match the dimensions: motor diameter 5-5/8" (142.88 mm), shaft 1/2" (12.7 mm) diameter and 6.06" (153.92 mm) long, frame 48Z, mounting stud. Compare them with your old motor before you order.
- Check the electrical data: 1/6 HP, 1075 RPM, 208/230 V, 60 Hz, single phase, 1.25-1.1 A. They must match the nameplate of your old motor.
- Check the rotation and the mounting position: rotation reversible, mounting orientation horizontal / vertical shaft down, 1 speed. Capacitor: 3 MFD, 370 VAC required.
- Isolate and lock out the power before working on a motor, and discharge its capacitor before you touch the terminals. Send a photo of the nameplate of the old motor on WhatsApp and we confirm the match.
Need it delivered to Manah, Saham and Al Hamra, or anywhere else in Oman? Ask for a quote for this motor; we reply with the price, availability and delivery time. More fan and blower motors and Marathon motors are on the site.
Specifications
| Motor type | PSC (permanent split capacitor) |
|---|---|
| Power | 1/6 HP |
| Speed | 1075 RPM |
| Voltage | 208/230 V |
| Current | 1.25-1.1 A |
| Phase | 1 |
| Frequency | 60 Hz |
| Number of speeds | 1 |
| Frame | 48Z |
| Motor diameter | 5-5/8" (142.88 mm) |
| Shaft diameter | 1/2" (12.7 mm) |
| Shaft length | 6.06" (153.92 mm) |
| Motor shell length | 3.25" (82.55 mm) |
| Overall length | 10.25" (260.35 mm) |
| Mounting | Stud |
| Mounting orientation | Horizontal / vertical shaft down |
| Rotation | Reversible |
| Enclosure type | TEAO (totally enclosed air over) |
| Enclosure material | Steel |
| Bearings | Ball |
| Insulation class | Class B |
| Service factor | 1 |
| Efficiency | 57.5% |
| Duty cycle | Continuous |
| Maximum ambient temperature | 40 °C |
| Thermal protection | Automatic |
| Capacitor | 3 MFD, 370 VAC required |
| Manufacturer model number | 048A11T2008 |
| SKU | FM-055 |
| Part no. | X411 |
| Brand | Marathon |
Compatibility
Listed as an OEM replacement for Lennox.
